Tube and Shell Type Heat Exchanger

Short Description:

Shell and tube heat exchanger, also known as row and tube heat exchanger. It is an inter wall heat exchanger with the wall surface of the tube bundle enclosed in the shell as the heat transfer surface. This type of heat exchanger has a simple structure, low cost, wide flow cross-section, and is easy to clean scale; But the heat transfer coefficient is low and the footprint is large. It can be manufactured from various structural materials (mainly metal materials) and can be used under high temperature and high pressure, making it the most widely used type.

Product Detail

Product Tags

product description

A shell and tube heat exchanger consists of components such as a shell, heat transfer tube bundle, tube plate, baffle plate (baffle), and tube box. The shell is mostly cylindrical, with a bundle of pipes installed inside, and the two ends of the bundle are fixed on the tube plate. There are two types of fluids for heat exchange: cold and hot. One flows inside the tube and is called the tube side fluid; Another type of flow outside the tube is called shell side fluid. To improve the heat transfer coefficient of the fluid outside the pipe, several baffles are usually installed inside the shell. Baffles can increase the fluid velocity on the shell side, forcing the fluid to pass through the tube bundle multiple times according to the specified path, and enhancing the degree of fluid turbulence. The heat exchange tubes can be arranged in equilateral triangles or squares on the tube plate. The equilateral triangle arrangement is relatively compact, with a high degree of turbulence in the fluid outside the pipe and a large heat transfer coefficient; A square arrangement makes cleaning outside the pipe convenient and suitable for fluids that are prone to scaling.

Tube and Shell Type Heat Exchanger (1)
Tube and Shell Type Heat Exchanger (2)
